Sirius 747 Hardware Kit

Sirius 747 Hardware Kit

$25.50 USD
$25.50 USD
Sale Sold out

**Hardware Package If there are any missing items, we will not send replacements. Please assess the risk yourself.
**The package does not include any .stl file,  flywheel, 130 flywheel motor, wire and battery.
**If you want to inquire about shipping costs in more regions, please send a message to contact us.

Package content inclub:

WOLVES CORE

050 Gear motor
   -1218-050 Gear motor 12V(762 RPM) QTY 1
The Wolves core Type A Dual Stage+ Pusher V5D 1.5
Capacitance
   -104 Qty 4
Micro Switches
-Omron SS-10GL13 QTY 1
Brass Insert
   -m2x3x3 QTY 1
   -m3x5.5x5 QTY 6
Socket Cap Screw
   -m3x30 QTY 1
Flat Head Self-tapping screw
   -m2x5 QTY 4
   -m2x8 QTY 14
   -m2x12 QTY 3
   -m2.6x8 QTY 5
   -m2.6x12 QTY 6
Spring
   -0.3x5x50 QTY 1
   -0.5x4x15 QTY 1
Set screw
   -m2x3 QTY 1
   -m3x5 QTY 3
XT-60
   -Male QTY1
Slotted Round Head Self-Tapping
   -M2.6x10x6 Qty8

 SIRIUS 747-MK2

SWITCH SNAP ACTION
   -SS-10GL Qty 1
   -SS-10 Qty 1
   -PBS05A 7mm Mini Push Button Switch Fixed Instant self-Locking Qty 1
Bearing
   -MF63ZZ 3x6x2.5mm  Qty 6
Brass Insert
   -m3x5x5 Qty 17
Flat Head Screw
   -M3x10 Qty 30
Head Hand Screws
   -M3x10 Qty 1
Cylinder Pin
   -m3x25 Qty 2
   -m4x40 Qty 1
Spring
   -0.3x3x10mm Qty 4
   -0.4x5x40mm Qty 2
   -0.3x4x20mm Qty 1
Flat Head
Self-tapping screw
   -m2x12 Qty 4
   -m2.6x5 Qty 2
   -m2.6x8 Qty 15
   -m2.6x12 Qty 6
   -m3x12 Qty 2
Screw nut
   -m4 Qty1
